10" OD GRINDER, Brown & Sharpe 1020U SWING DO
10" OD GRINDER, Brown & Sharpe 1020U SWING DO
(MADE IN USA) "HIGH-PRECISION"
UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER
MODEL: 1020U S/N: 521-1020-228 NEW: 1975
SWING OVER TABLE .................................... 10"
DISTANCE BETWEEN CENTERS, NOMINAL .................... 20"
DISTANCE BETWEEN CENTERS, MAXIMUM ................ 22-3/4"
WHEELHEAD SPINDLE SPEEDS (3) ...... 2100, 2400 & 2800 RPM
GRINDING WHEEL SIZE ........................ 12" X 1" X 5"
MINIMUM GRINDING WHEEL WIDTH ........................ 3/8"
SWIVEL AT THE WHEELSLIDE ........... 90 DEGREES EITHER WAY
WHEEL SPINDLE SWIVELS .............. 90 DEGREES EITHER WAY
INFINITELY VARIABLE SPINDLE SPEEDS ........ 60 TO 600 RPM
HEADSTOCK SPINDLE NOSE TAPER ....................... A2-5"
HEADSTOCK SWIVELS EITHER SIDE OF ZERO ......... 90 DEGREES
INFINITELY VARIABLE TABLE SPEED .......... 3" TO 150" IPM
SLOW ................................................ 0.1"
FAST ................................................ 1.5"
DWELL AT EACH OR ALTERNATE TABLE REV. ..... 0 - 2-1/2 SEC.
TABLE SWIVEL, SCALES FOR ANGULAR SETTING ...... 8-1/4 DEG.
SCALES-TAPER PER FT. .............................. 3-1/2"
MAX. TRAVEL OF WHEELSLIDE ............................ 5"
CROSSFEED HANDWHEEL GRAD. ....................... 0.00002"
AUTOMATIC CROSS FEED, REDUCTION IN DIAMETER
OR WORK AT EACH OR ALTERNATE REVERSALS .. 0.0001" - .003"
HAND FEED PER REV. OF HANDWHEEL:
SLOW ................................................ 0.1"
FAST ................................................ 0.3"
TAILSTOCK SPINDLE TAPER .........................#7 JARNO
TAILSTOCK SPINDLE TRAVEL ............................ 5/8"
APPROXIMATE WEIGHT ............................ 5,100 LBS
DUAL RIGHT OR LEFT END WHEEL MOUNTING
SWIVELLING AT WHEEL SPINDLE HEAD OR AT THE WHEEL
SLIDE PERMITS ANY COMPOUND SETTING REQUIRED IN
COMBINATION STRAIGHT AND TAPER GRINDING,
INFEED HANDWHEEL GRADUATED TO READ TO 0.000020"
AUTO INFEED OF WHEELHEAD @ TABLE REVERSALS
DUAL LIVE/DEAD WORKHEAD SPINDLE
WORKHEAD HAS INFINITELY VARIABLE SPINDLE SPEEDS
SELF-CONTAINED HYDRAULIC SYSTEM
SWING DOWN INTERNAL GRINDING ATTACHMENT W/SPINDLE
4-JAW CHUCK MOUNTED ON WORKHEAD
** MACHINE WAS USED IN A SCHOOL. THIS MACHINE
IS UNUSUALLY PRISITINE, WITH VERY LOW HOURS! **
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
Machine Location: HARRISON, NJ
