Jca 5.5 TO13.5 ghz microwave power amplfier


JCA / Endwave microwave power amplifier,
Maximum gain is about 30 to 34dB
Saturated output power is about 24-30dBm
Supply voltage is 12VDC at 540 mA
It has the following pins on top:
Model number is: JCA1011-386PSAD2
(1011 is the frequency range, the rest of the numbers are options: phase shift, detector and reference)
Items are used, but in good working conditions.
1.50 for every extra amplifier
Pictures with 10dB attenuator at the input. More images at:
