Lytron swep compact liquid-to-liquid heat exchanger
Liquid-to-Liquid Heat Exchangers - Copper Brazed Plate. IT IS A SWEP Heat Exchanger with a Lytron Label. This is not the exact unit in the picture, in fact the unit I'm selling has 1/2 inch pipe welded onto the sweat fittings. THE UNIT WAS ONLY USED FOR A SHORT PERIOD OF TIME AND IS IN PERFECT CONDITION.
Max working temperature: 365°F Primary & Secondary
Max Working(PSI): 450 Primary & Secondary
Volume: 13.73 Primary, 15.25 Secondary
Brazed plate liquid-to-liquid heat exchangers are much smaller and lighter than conventional shell-and-tube heat exchanger designs. They are copper-brazed for compatibility with water, EGW, and other common coolants, or nickel-brazed for high purity and corrosive coolants.
Stainless steel sheets in the heat exchanger are brazed together at the edges and at a matrix of contact points for a reliable and rugged part, and have an extremely efficient herringbone construction for maximum heat transfer. Lytron’s brazed-plate heat exchangers are unsurpassed for liquid-to-liquid heat transfer. Their innovative design packs maximum performance into a compact and reliable package.
* High performance in a small package: Lytron’s liquid-to-liquid heat exchangers are up to 80-90% smaller in volume and weight than a conventional shell-and-tube design. The counterflow design utilizes stainless steel sheets stamped with a herringbone pattern of grooves, stacked in alternating directions to form separate flow channels for the two liquid streams. This allows 90% of the material to be used for heat transfer, making it extremely efficient.
* High reliability: The plates are brazed together at the edges and at a matrix of contact points between sheets, ensuring that the heat exchangers are highly reliable and rugged.
* Copper and nickel-brazed versions for compatibility with a wide range of fluids: We offer copper-brazed units for use with water, EGW and other common coolants. Our nickel-brazed units are appropriate for use with deionized water, high purity, and corrosive fluids.
* High operating temperatures and pressures: Copper-brazed units can be operated at temperatures of up to 383°F (195°C) and pressures up to 450 psig (31 bar). Nickel-brazed units can be operated at temperatures of up to 662°F (350°C) and pressures up to 232 psig (16 bar).
These are Instructions for a similar product that is exactly the same.
