Tek 7612D service and operator manuals
Another rare Tektronix manual digitally “Re-masteredâ€
THESE SCANS ARE BOOKMARKED IN GREAT DETAIL
TABLE OF CONTENTS, THEORY of OPERATION, ADJUSTMENT and CHANGE sections
ALL ELECTRONIC PAGE NUMBERS MATCH THE ORIGINAL MANUAL PAGE NUMBERS
(i.e. 2-1,2-2,2-3, etc. NO MORE GUESSSING WHERE YOU ARE)
1. Tektronix 7612D PROGRAMMABLE DIGTIZER, OPERATOR:
This volume covers General operation and programming commands. P/N 070-2386-00, 164 pages in 81 MB, Revised printing July 1983.
2. Tektronix 7612D PROGRAMMABLE DIGTIZER, SERVICE:
This volume covers basic operation and programming, installation, service, maintenance and calibration. It also includes complete parts (mechanical and electrical), component location grids, schematics, and adjustment locations. P/N 070-2387-00, 582 pages in 116MB, revised printing date June 1983 with changes through January 1984, Serial numbers directly referenced B010100 through B031113.
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out.
Samples of specific pages from the actual manual cheerfully supplied !
SATISFACTION GUARANTEED OR YOUR MONEY BACK !
