RAM-TYPE EDM, Hansvedt SM-18 CINTROJET H-PULS
RAM-TYPE EDM, Hansvedt SM-18 CINTROJET H-PULS
HANSVEDT "VERY LARGE CAPACITY" RAM TYPE EDM
MODEL: CINTROJET 18E S/N: J12101 NEW: 06/1992
WORK TABLE SIZE ...................... 41" x 25- 1/2"
LONGITUDINAL TABLE TRAVEL ............ 40"
CROSS TRAVEL ......................... 20"
WORTANK SIZE (INSIDE DIMS.) .......... 60" x 30" x 18"H
PLATEN SIZE .......................... 10" x 15- 3/8"
PLATEN TO TABLE ...................... 11" MAX., 23" MIN.
THROAT DISTANCE ...................... 22- 1/4"
RAM TRAVEL ........................... 12"
MAX. WEIGHT ON PLATEN ................ 1,650 LBS.
MAX. WORKPIECE WEIGHT ON TABLE ....... 4,000 LBS.
DIELECTRIC RESEVOIR (MACHINE BASE).... 210 GALS.
WORKTANK TANK CAPACITY ............... 140 GALS.
HYDRAULIC RESEVOIR ................... 20 GALS.
APPROX. WEIGHT ....................... 10,700 LBS.
APPROX. DIMS. ........................ 116" x 114" x 93"H
HANSVEDT "H-PULSE" MODEL #1506 150 AMP POWER SUPPLY
-SIMPLE, UNDERSTANDABLE SPARK & SERVO CONTROLS
-SERVO CONTROLS FEATURING DITHER, MANUAL, EDGE FINDER,
AUTO RETRACT, AUTO LOCK, ORBIT STOP, ORBIT LOCK,
-LOW PEAK CURRENT, ARC DURATION (.5 TO 1843 MICROSECONDS)
& % ON-TIME SELECTIONS FOR ULTRA-FINE FINISHING
"FUTABA" 3-AXIS DIGITAL READOUT DISPLY
MACHINE IS WIRED FOR 3/60/440 VOLTS
** EXCEPTIONAL CONDITION & APPEARANCE **
Machine Location: HARRISON, NJ
