Tek 5441 manual A3 +A4 +2 resolutions +text search
Tektronix 5441 Oscilloscope Plugin Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
This Manual includes operating, maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams. Both resolution PDFs are bookmarked, hyperlinked, and feature both chapter-page and sequential page numbering. The smaller, faster "research" PDF is also text-searchable!
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 600dpi grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes (if any): 400-600dpi 24-bit color
Chapter-Page (same as in paper manual) -AND- sequential page numbers!
Foldouts scanned & provided in 17x11" -AND- 8.5x11" scans!
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
