Hp 3852A data acquisition and control system used
You can easily configure an hp 3852A data acquisition and control system to meet your needs for measuring physical parameters. The 3852A is set up to handle many different transducer inputs including thermocouples, thermistors,
RTDs, and strain gages, as well as being ready to measure
dc volts, currents, resistances, pulse counts,
frequencies, and more. The 3852A mainframe has eight (8)
slots for plug-in function modules, and has provisions for
extending the mainframe (the 3853A) for large systems
High Speed and Accurate Analog in One System
Built-in, 68000-based intelligence
Maximum channels/system differential: 1848
Maximum channels/system single-ended: 4620
Maximum measurement speed (readings/second): 100,000
Resistance (maximum reading): 3 Mohm
Count (maximum frequency): 200kHz
Analog output DCV (range): ± 10V
Analog output DCI (range): ± 20mA
Maximum internal memory: 4Mbyte (option)
Backplane type: Proprietary backplane
