Tektronix 604 crt display monitor xy display scope


Tektronix 604 CRT Display Monitor XY Display Scope
The 604 Display Monitor (6 1/2" CRT) meets the requirements for applications such as pulse-height analysis, infrared detection, data communications systems testing, component & logic testing, vibration analysis, medical instrumentation, phase shifts & frequency ratios using Lissajous figures, & many others.
X & Y bandwidths are DC to 2 MHz at 3 dB down from 80% of full screen. The deflection factor is nominally 1 V full scale. It is internally adjustable from 0.5 V to 2.5 V full scale. An internal 5X attenuator extends the deflection factor range to 12.5 V full scale. The X-Y phase difference is not more than 1° to at least 500 kHz. On the Z-axis, the bandwidth is DC to 5 MHz over usable range. The sensitivity is adjustable from +1 V to +5 V for full intensity control. 0 V input cuts intensity off.
IF THE PICTURES DOES NOT APPEAR IN ITS GIVEN SPACE, RIGHT CLICK ON THE SPACE AND SELECT SHOW PICTURE.
