Watts 530C 1/2" calibratd pressure relief valve 0371271


Adjustable Pressure Range 50 to 175psi
Series 530C Calibrated Pressure Relief Valves are used in commercial, residential and industrial applications to protect against excessive pressure in systems containing water, oil, or air. It consists of a bronze body construction with NPT threaded male inlet and NPT threaded female (drain) outlet connections, stainless steel spring, brass bonnet, Buna-N disc, and Buna-N O-ring. Series 530C has a calibrated adjustment feature for setting the valve to the required relief pressure, and is ideal for by-pass thermal expansion pressure relief (not ASME approved).
For Commercial, Institutional and Industrial Application
Series 530C Calibrated Pressure Relief Valves are spring operated brass valves designed for use only as protection from the build up of excessive pressure in systems containing water, oil or air. Series 530C valves incorporate a calibrated adjustment feature for setting the valve to the relief pressure required. These valves are ideally suited for bypass thermal expansion relief.
• Calibrated adjustment feature for setting valve to relief pressure required
• Adjustable range 50 – 175psi (3.4 – 12.1 bar)
• Buna-N disc on machined body seat
• Inlet (bottom), male NPT threaded
• Outlet (side), female NPT threaded
Maximum Temperature: 180°F (82°C)



Watts 530C 1/2
