Hp/agilent 8904A multifunction synthesizer w/opts
The HP/Agilent 8904A multifunction synthesizer generates accurate sine waves from 0 Hz to 600 kHz with 0.1 Hz resolution and one channel. The 8904A also has five other standard functions: square, triangle, ramp, from 0 Hz to 50 kHz plus dc, and Gaussian white noise. All waveform values in the 8904A are digitally calculated in real time by Agilent Technologies' Digital Waveform Synthesis IC yielding 12-bit digital accuracy. Full GPIB programmability is also included standard on the 8904A. Features: *Sine to 600 kHz, square, ramp, triangle to 50 kHz *12 bit direct digital synthesis *Tone, DTMF, digital, Hop Ram sequence modes *One or two outputs *One to four internal channels *AM, FM, Phi-M, DSBSC, and pulse modulation *Unit to unit phase synchronization. DC Amplitude: *Range: 0 to +/- 10 V p-p open circuit Accuracy: Larger of +/- 20 mV or +/- 2.1% . This is a one channel, 600 ohms output generator.
Reasonable offers are welcome! REASONABLE ONES!
This is my website for more equipment you may need: http://aaaequipmentresources.com/index.html
