Tektronix 564 Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
Full Commercial Manual - NOT MILITARY!
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
We appreciate your considering purchase of these very high-resolution and standard resolution scanned copies of the SERVICE AND OPERATING MANUAL for the Model 564 Oscilloscope. These volumes are each composed of the entire contents of the original commercial manual (we are not one of those outfits selling you the free military download manuals your tax dollars paid for in the first place). We supply PDFs in both a very high res, sometimes larger than and sometimes merely equal to the competition's, and a faster, less resource-demanding "standard" resolution.
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus full operating information. It is fully-bookmarked and hyperlinked, plus features both the chapter-page and sequential page numbering systems.
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 400-600dpi grayscale (contrast adjusted, content-dependent)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color: 400-600dpi 24 bit color
Foldout Pages Supplied in -BOTH- 8.5x11" -AND- 11x17" Scans!
Chapter-Page -AND- Sequential Page Numbering!
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. It's also bookmarked, hyperlinked, uses both page numbering systems -and- is text-searchable as well!
Also, we include a "foldouts.pdf" with the foldout pages from the manual scanned 17x11". Please note that the foldout pages are ALSO included as A4 scans (sectioned as 8.5 x 11" pages, in other words) in the main manual for ease of printing on standard printers.
