Cec webdaq/100 data logging networkable a/d digital i/o
Complete Recycling Solutions CEC webDAQ/100 Multi-Function Data Logging Networkable A/D, Digital I/O and D/A Device DescriptionThis is a new CEC webDAQ/100 unit. Included is the power supply and a thermocouple adapter. No software or literature is included.
Every webDAQ/100 contains a complete web server built right into the box. Just connect it to your network, or direct to an Ethernet card in your computer, and open your web browser. You get complete control over channels, rates and other acquisition parameters, a dynamic view of your data, and direct download in a variety of formats.
* Data Logging and Acquisition from your web browser - No Programming Required
* Direct Computer-WEBdaq comunication over a LAN, serial port or remote access
* Data Acquisition - 500 KHz, 32 Channels, 12 Bit A/D
* Removeable Screw Terminals
* Configurable Report Formats
* E-Mail Data Reports and FTP Scheduled Automatic Reports
* Command-line interface and programming
High Performance: 500 KHz, 32 Channels, 12 Bit Accuracy
webDAQ/100 uses the highest quality analog components together with digital signal processor (DSP) technology to bring you top performance. Up to 32 separate signals can be acquired simultaneously, or terminals can be combined in differential input pairs for higher noise rejection. Any combination of single-ended and differential pairs can be used.
Most data acquisition products have a single sampling clock. But real-world signals don't all happen at the same rate. That's why webDAQ/100 provides up to four sampling rates during a single acquisition. Slow signals like temperatures can be sampled less often, and fast signals like audio waveforms can be gathered at high rates.
Your sensors don't all measure volts and bits - they sense temperature, pressure, resistance, strain, and more. webDAQ/100 provides acquired data directly in engineering units. You can configure a webDAQ/100 channel to process your inputs using your choice of scaling: linear, quadratic, current, resistance divider, resistance bridge, strain gage (7 different circuits), RTD, and thermocouples (B,E,J,K,R,S,T,N). Comprehensive built-in help shows you how to wire your sensors to webDAQ/100.
webDAQ/100 offers both digital and analog triggering. In fact, acquisition can be configured to start or to stop on either type of trigger, or to stop after a desired amount of data has been collected.
8 Analog Outputs For Circuit Stimulus
With eight independent waveform-quality D/A outputs, webDAQ offers far more capability than most data acquisition products. Some sensors such as RTDs and strain gages require an excitation voltage source, which can easily be provided directly by webDAQ. The outputs are conveniently grouped with the input terminals.
Removeable Screw Terminals, No Long Cables
Since webDAQ/100's signal connections are built right in, you can connect your sensors right to the unit, with no external cables and junction boxes required. A direct connection also provides high signal quality with low noise.
