Honywell AT175A1008 foot mount 120/208/240V transformer
Foot mounted 120/208/240 Vac Transformer with 9 in. lead wires and metal end bells. Provide power to 24 Vac circuits in heating/cooling control systems. Intended for use in systems with predictable, uniform loads. Can be used in any application that does not exceed the listed ratings.
• Color-coded leadwires for primary connections and screw terminals for secondary connections, fixed 1/4 inch (6 mm) male quick-connects or color-coded leadwires for both primary and secondary, are standard.
• Meet NEC Class 2 requirements.
• Meet Underwriters Laboratories Inc. Standard UL 1585 and are identified. Class 2 not wet, Class 3 wet.
Electrical Ratings -Primary Voltage
Electrical Ratings -Secondary Voltage
Foot mounted, plate mounted on 2x4 in. or 4x4 in. outlet box , clamp mounted using outlet box knockout, or panel mounted
Electrical Connections (Primary)(in.)
Electrical Connections (Primary)(mm)
Electrical Connections (Secondary)(in.)
Electrical Connections (Secondary)(mm)
3 3/16 in. high x 2 3/8 in. wide x 3 1/8 in. deep
81 mm high x 60 mm wide x 79 mm deep
Approvals, Underwriters Laboratories Inc
UL Listed: A,C,F models. File # E14881
Approvals, Canadian Standards Association
