New rcm flo-gage flow meter 1/4-71-r-4_f 1/2" 4GPM
NEW RCM Flo-Gage Flow Meter 1/4-71-R-4_F 1/2" 4GPM
The 7000 series flow meter is a threaded FNPT connection standard. and FBSP parallel threads available on request for Bronze and Monel meters. Solder connections are also available in 1" and 1 1/2" Bronze bodies. The flow meters can be ordered in Bronze, SST and Monel in pipe sizes ranging from 1/4" to 3".
C Calibrated for Specific Gravity
D Gasketed Case (NEMA 4X, IP66)
D2 Gasketed Case w / Condulet (NEMA 4X IP66)
F Aluminum Housing w / Plastic Dial Crystal
F2 Aluminum Housing w / Glass Dial Crystal
H High Pressure Service (400 psig max.)
J Peak Flow Indicator (ABS Housing only)
K Saturated Steam Service (120 psig max.)
T Expanded Temperature Service (-80ºF - 350ºF)
V High Viscosity Service (500cps max.)
Pressure Max.: 180 psig (12.6 kg/cm²) 400 psig (28.1 kg/cm²)
Pressure Min.: 10 psig (0.67 kg/cm²) 10 psig (0.67 kg/cm²)
Temp. Max.: 212 ºF (100ºC) 350 ºF (177ºC)
Temp. Min.: -30 ºF (-34ºC) -80 ºC (-62ºC)
Bellows: Bronze Monel, 316 SST, Inconel
Seals: Buna-N Viton, EPR, Teflon
Crystal: Polycarbonate Glass, Plastic
F Aluminum Housing w / Plastic Dial Crystal
If you require more detailed specifications, please contact the manufacturer for technical support.
