Fluke t+pro electrical testers
We are wholesaler and Distributor of all Electrical supplies brand name.
Email: ****@yahoo.com
If you need any assistants please call us.
We are representing whole line of fluke please call us if you need any special order.
Safer than traditional solenoid testers and fully compliant with NFPA 70E*
The T+PRO and T+ Electrical Testers offer all the functionality that electricians look for in volt meters and voltage and continuity testers:
* Both have three ways to detect ac/dc voltage: light, sound, and vibration
* Both offer the added functionality of a GFCI trip and continuity beeper, plus the convenience of a built-in flashlight
* The T+PRO Electrical Tester comes with a rotary field indicator for troubleshooting three-phase systems, resistance measurement to 9.99 KOhms, as well as a backlit LCD display for easier viewing
Safer than traditional solenoid testers:
* CAT IV 600 V, CAT III 1000 V rated
* When used properly per Article 110.9 Use of Equipment (A) Test Instruments and Equipment.
Features and benefits of the T+PRO and T+:
* 3 forms of ac/dc voltage indication: light, sound, and vibration for added user protection and convenience
* Detect live voltage even when the batteries are dead
* Extra heavy-duty, replaceable test leads for more flexibility and durability
* CAT IV 600 V, CAT III 1000 V rated for added user protection
* Bright LED flashlight for work in poorly lit areas
* On/Off switchable beeper, selectable according to your environment
* Compliant with latest NFPA 70E recommendations*
* Replaceable test probes for added flexibility and convenience
* Convenient probe storage on the back
* Probe holder for easier testing
* Hazardous voltage warning light for added user protection
* Test lead strap included for better test lead management
* AC/DC Voltage: 12 V – 600 V on LED bar, 10.2 V – 600 V on LCD (LCD on T+PRO only)
* Auto-off saves battery power
-10 °C to 55 °C (14 °F to 131 °F)
-30 °C to 60 °C (-22 °F to 140 °F)
0 °C to 30 °C (32 °F to 86 °F): 90 %
30 °C to 40 °C (86 °F to 104 °F): 75 %
40 °C to 50 °C (104 °F to 122 °F): 45 %
10,000 m (approx. 32,808.4 ft)
Sinusoidal vibration per MIL-PRF-28800F for a Class 2 instrument
ISA-82.02.01 (IEC 61010-1 Mod) Second Edition, CAN/CSA-C22.2 No. 61010-1 Second Edition, IEC 61010 - 1 to 1000 V CAT III/600 V CAT IV
Indefinitely for voltages up to 240 V
For voltages between 240 V and 600 V the duty cycle is 30 s on / 300 s off
For voltages above 240 V the tester must connect to a voltage source only for a MAXIMUM of 30 s and then disconnect for a MINIMUM of 300 s
LEDs turn on at voltages > 30 V ac/dc ± 35 %
12 V, 24 V, 48 V, 120 V, 208 V, 240 V, 277 V, 480 V, 600 V
LED voltage indication levels for Canadian version
12 V, 24 V, 48 V, 120 V, 208 V, 240 V, 347 V, 480 V, 600 V
LEDs turn on between 90 % and 100 % of the indicated voltage on the LED, except for the 12 V LED which turns on between 50 % and 100 %
0.1 V for voltages < 50 V, 1 V for voltages ≥ 50 V
0.01 kΩ for resistance measurement (For T+PRO Only)
100 V - 150 V @ 6 mA - 9 mA ac, 150 V - 240 V < 12 mA
1.3 in x 2.15 in x 7.6 in (3.3 cm x 5.46 cm x 19.3 cm )
*When used properly per Article 110.9 Use of Equipment (A) Test Instruments and Equipment.
