Digital thermometer k-type thermocouples temps sensor


Digital Thermometer K-type thermocouples temps sensor
This compact and tough handheld digital thermometer has been designed to use with external K-type thermocouples as a temperature sensor. Everything you need to get started is here – including two K-type thermocouples.
This is a Two K-type model and is equipped with a Differential Temperature Measurement function. At the press of a button, the thermometer will display the difference in temperature between the two thermocouples – this will be the temperature of thermocouple T1 minus the temperature of thermocouple T2.
The temperature indication follows the IEC 584 temperature/voltage tables for K-type thermocouples.
* Differential Temperature Measurement
* Select between Celsius and Fahrenheit
* Overload display alert when input exceeds measurement range
* Hold mode – holds current reading and ceases taking other measurements
* Easily portable – take it anywhere you need it
* Display: 3 ½ digit liquid crystal display with maximum reading of 1999
* Power Current: approx DC 3mA (typical)
* Dimensions of Thermometer: 5.5 (w) x 11.5 (l) x 3 (d)cm (2.5 x 4.7 x 1”)
* Dimensions of Screen: 4 (w) x 2 (l)cm (1.6 x 0.8”)
* Length of Thermocouples: 75cm (29.5”)
* Probe measurements: 155 x 70 x 35mm - length x width x height)
* Weight (Including Battery): 190g
* Temperature Scale: Celsius or Fahrenheit
* Measurement range: -50°C to 1300°C (-58°F to 2372 °F)
* Thermocouples measurement range: -50°C to 900°C (-58 °F to 1652°F)
* 0.1°C ± (0.3%rdg +1°C) -50°C to 199.9°C
0.1°F ± (0.3%rdg +1°F) -58°F to 199.9°F
1°C ± (0.3%rdg +2°C) -50°C to 1200°C
1°C ± (0.6%rdg +2°C) 1200°C to 1300°C
1°F ± (0.3%rdg +2°C) -58°C to 1200°C
1°F ± (0.6%rdg +2°C) 1200°F to 1999°F
* Temperature Coefficient: 0.1 x the applicable accuracy spec per °C from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F)
* Input Protection: 60V DC or 24V AC max input voltage on any combination of input pins
* Reading Rate: 2.5 times per second
* Input Connector: Accepts standard miniature thermocouple connectors
Brand new and Boxed. Includes:
