Busio-sw (busio push button) basic stamp, pic, atmel


The board can be use with MR-BusIO-MAIN board or stand-alone. PCB size is 0.63” x 2.80”
There are three ways to use this board:
As a switch input: When user press the switch, logic LOW is apply at the I/O pin. The indicator LED is also illuminated. I/O pin read logic HIGH when the switch is de-press.
As a VR (Variable Resistor): This is optional. User has to solder 10 POT on to the board. It’s operating as a voltage divider of VCC.
As an 1-Wire Thermometer (DS18S20): This is optional. User has to solder 3-PIN DS18S20 on to the board, pin1 GND, pin2 DQ, and pin3 VCC. The 1-Wire data can be read from an I/O pin. Do not connect VR when using this option.
For more information please see: MR-BusIO-SW User Manual
“This is sold fully assembled and tested”
For more exciting products please visit WWW.MICRORESEARCH.US
