13" ENGINE LATHE, Sharp 1340VS Digital Variab
13" ENGINE LATHE, Sharp 1340VS Digital Variab
MODEL: 1340VS w/Digital Variable Speed
- variable speed spindle drive with digital display
- hi-low gear shift for spindle speed, range from 40 - 2,000 RPM
- hardened & ground gears in headstock
- directional control of carriage feed in front of apron for easy operation
- jog button for easy engagement of gears
- induction hardened & ground bedways for rigid structure
- spindle supported by 2 high precision tapered roller bearings
- carriage equipped with overload clutch to protect gears & screws
- available for 3 phase or single phase electrics operation
- electrically activated foot brake for quick stopping action
- built-in cabinet for tools storage
Swing over gap, width: 18-1/2"
Spindle nose type: D1-4 Camlock
Spindle Speeds (Inf. Variable): 40 - 2,000 RPM
Longitudinal feeds - inch per rev (40): 0.0016 - .0046
Cross feeds - in per rev (40): 0.0005 - 0.015
Metric threads (42): 0.5 - 12mm
Leadscrew pitch, diameter: 8 TPI, 1"
Motor: 3 hp (220 Volts, Your Choice of Single Phase or 3 Phase)
440 Volt Operation requires an optional transformer
Net weight (approximately): 1,580 lbs
coolant system, 4-way toolpost, steady rest, thread dial, foot
brake, center sleeve (MT #5 x #3), dead centers (MT #3) tool kit,
removable gap block & splash guard.
OPTIONAL EQUIPMENT (Call for prices)
Follow rest, digital readout system, taper attachment, micrometer
carriage stop, 3-jaw scroll chuck (8"), 4-jaw chuck (8"), face plate
(12"), single toolpost, live center (MT #3), & drill chuck.
Machine Location: HARRISON, NJ
