New adjustable lcd digital multimeter mastech M9508
Digital Multimeter Mastech M9508
• LCD display can be adjusted to angle up to 70 degree
• Display: 35x61mm LCD, max. reading 1999 counts
• Engineering unit annunciators on all ranges
• DC Voltage: 200m/2/20/200V±0.5%, 1000V±0.8%
• AC Voltage: 200mV±1.2%, 2/20/200V±0.8%, 700V±1.2%
• DC Current: 2m/20mA±0.8%, 200mA±1.2%, 20A±2.0%
• AC Current: 200mA±1.8%, 20A±3.0%
• Resistance: 200m/2k/20k/200k/2MΩ±0.8%, 20M&Ω±1.0%
• Capacitance: 2n/20n/200n/2µ/20µF±4.0%
• Continuity checking with buzzer
• Weight: approx. 380g (including battery)
