> 50 pc 0.5 watt strawhat 8MM 140° warm white led 80KMCD
50 pc 0.5 watt strawhat 8MM 140° warm white led 80KMCD
50 PCS High Power 0.5 Watt Warm White LED 8mm 140° 5-Chips StrawHat LED 100mA 80,000mcd
* Long lasting (over 100000hours)
8mm 140°StrawHat 5-Chips High Power WARM WHITE LED
* Luminous Intensity-MCD: Avg: 80,000mcd Max: 100,000 mcd
* DC Forward Voltage: Typical: 3.4 V Max: 3.8V
* Lead Soldering Temp:260°C for 5 seconds
1.All dimensions in mm tolerance is 0.2mm unless otherwise noted.
2.An epoxy meniscus may extend about 1.5mm down the lead.
3.Burr around bottom of epoxy may be 0.5mm max.
*Typical Electrical & Optical Characteristics ( Ta = 25°)
*Absolute Maximum Ratings (Ta = 25°C)
(3mm from the base of the epoxy bulb)
*Pulse width ≦0.1msec duty ≦1/10
If You Have Any Question, Please Contact Us at ****@163.com
* Item must be returned in original packing.
* Standard Airmail US$10.00 (7-14 Business days). No addtional/others charge and less..
* Delivery will be made by registered Airmail from Hong Kong to World Wide with official HK post office registered ID#.
* All items are Brand New, unless stated otherwise
* We are not responsible for uninsured items that are stolen, lost, damaged, sent to unconfirmed address or P.O./A.P.O/F.P.O boxes
