Summation sigmaseries HAS10 high accuracy switch 5110A
SigmaSeries High Accuracy Switch
~ TESTED IN A SUMMATION TESTFRAME - FULLY FUNCTIONAL ~
The HAS10 is typically used as a signal multiplexer for DMM10 enabling it to make up to 20 separate floating voltage measurements or resistance measurements. A common guard input for all 20 channels is provided. A switched guard may be used in a 10 channel mode. External signals are connected to one or two DMM10s through an internal connection to the High Accuracy bus (HA.BUS). Multiple HAS10s may be connected to each other or to the HFS10 over the HA.BUS. In addition to being a multiplexer for the DMM10, the HAS10 can be used as an actuator to connect external signals together.
* 20 two-terminal or 10 four-terminal switching
* Less than 1 uV thermal offset
* 2 High Accuracy Bus connections
* Expandable to 460 channels
P/N: 1700-104485 Rev. A (9000-102098)
~ International: *International Surface Parcel (4-6 weeks) or XpressPost International (5-8 Business days) - $39.95 & $69.95 respectively
PHOTOS BELOW ARE OF THE ACTUAL MODULE
