Chiyoda sp-40ST cnc tube bender


CHIYODA MODEL SP-40ST HYDRAULIC, ROTARY, CNC TUBE BENDER*
Maximum Bend Radius: 8"
Maximum Tube Length Over Mandrel (If Equipped): 118"
Maximum Tube Lenght w/o Mandrel: 18'
Maximum Degree of Bend: 0 to 190 Degrees
Plane: 0 to 360 Degrees
Productivity (Bends per Hour): 1,200 - 1,400
Speeds: Degree of Bend: 170 Deg./Sec.
Plane of Bend: 210 Deg./Sec.
Feed: 31.5"/Sec.
Clockwise Rotation
EQUIPPED WITH:
CNC Control (3-Axis; Process Number: 0-30)
Dual Radius Bend Option (Hydraulically Actuated)
Clamp and Pressure Die Holders
Motorized Carriage for Plane of Bend and Distance Between Bend Stops
Collet Device for Carriage; Oil Chiller
Direct Acting Pressure Die; Swinging Arm Safety Device
10 HP AC Main (Pump) Drive Motor; Electrical Controls
Push Button or Electric Foot Switch Operation
Operator Control Console (Mounted on Frame)
BENDING CAPACITIES (MILD STEEL):
Tube: 1.50" x .078" Wall
Pipe: 1.50" x .065" Wall
Bar (Round): .70" OD
Approximate Overall Dimensions: 183" L-R x 53" F-B x 60" H
Approximate Weight: 8,000 Lbs.
Serial Number: T8-494-10.15 (New 1994)
P2 F.O.B. Elk Grove, IL - $ 59,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
Email us at ****@PerfectionMachinery.com
Call our Sales Staff at 1-(***)-254-8808
Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes.
Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power.
