Tek TM501 service/opr manual in 2 res +txtsrch +extras
Tektronix TM501 Service/Ops Manual in both Very High and in Standard Resolution PDF on CD
Why settle for just one resolution? You get them both!
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
HERE is a link to this item with 38 TM500 series plugin manuals.
Also includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF, as well as a fully bookmarked, hyperlinked and text-searchable scan of the entire "TM500 Rear Interface Data Book", a "TM500 Modular Test & Measurement Instruments" Descriptive 44 Page TM500 Series Brochure and the Publication "Suggested Power Supply Circuits for The TM500 Blank Plug-In Kit" at no additional charge!
This manual covers the Tektronix TM501 Power Module. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here.
Two PDFs of the manual are provided, in two resolutions. One is:
Text pages scanned at 300dpi (minimum)
Text with Drawings at 600dpi (minimum) black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
The very high resolution looks nice, but for many purposes uses excessive resources. You can copy the large file to the hard drive in an attempt to achieve acceptable performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have such high resolutions for those times you need higher definition (printing), we include a second scan in standard resolutions for daily research and use on the bench.
The second scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
On the CD you'll receive the large "very high resolution" file, plus the smaller, faster and often more useable text-searchable version. ALL original manual pages are supplied. Marketing experts proudly advertise page counts and file sizes, but since those counts and sizes are so often artificially inflated with advertising, shareware beg screens and/or blank pages, we refrain from joining them and instead assure you that these manuals are complete and are scanned in the specified resolutions.
