Rb bed type vertical mill
http:// /images/islogo_lg.gif
Serial No. 76120397 New 1987
Longitudinal Table Travel: 28"
Head Vertical Travel on Column: 16"
Distance From Spindle Center to Column Ways: 15-1/2"
Max. Distance Spindle Nose to Table Top: 19"
Min. Distance Spindle Nose to Table Top: 3"
Spindle Speed, Variable: 60 - 4500 RPM
Milling Head Tilts, Left to Right: +/- 90 Deg.
Spindle Nose Taper: #30 MT
Overall Machine Size: 60" x 50" x 80" High
Machine Weight, Approx.: 3,000 Lbs.
Power Longitudinal Table Feed
3 HP Milling Head Motor 220/440/3/60
All Items Subject to Prior Sale
Be Sure to Verify Specs & Condition Prior to Purchasing
