Tektronix 7B53A service manual


The Operator’s Manual, P/N # 070-1252-00. This volume comprises 32 pages scanned from an original Tektronix manual to a file size of 61 MB in PDF format.
The Service Manual is a recent one, P/N 070-1342-01, revised printing May 1988. This volume comprises 198 pages scanned from an original Tektronix manual to a file size of 198 MB in PDF format. This volume includes condensed operating instructions plus detailed maintenance and calibration procedures. It also includes complete parts lists, board component locators and schematic diagrams.
Text with photos: 600dpi, grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and board overlays with color notes: 256 colors 600dpi
Large fold out schematic pages are scanned in sections at 8.5 X 11 with a typical over lap of 1" to insure easy piecing if you print them out.
